Pt1000 RTD, 5 in (125 mm) Probe, Thin Tip, Adjustable Length

This PT1000 RTD probe can be used for measuring temperature of air or liquid. The probe is protected with 304 stainless steel sheath. The thin tip of this probe (1/8 inch or 3.0 mm in diameter) ensures a fast response.

This probe can be purchased with optional compression fitting for mounting. Seven different type of fittings are offered. The upper probe in the picture is the standard package without fitting. The bottom probe is with an optional 1/8" NPT threaded compression fitting. The fitting can be used to form a liquid or pressure tight seal. With fitting, user can also adjust the exposed probe length. Please select the fitting option when place the order. If you want to order mounting adapters separately, please see AD-KEGTS.

1/8'' NPT	1/4'' NPT	1/4'' BSP	M8 x 1	M10 x 1	Weld-in Carbon	Weld-in SS


Left: A PL31K25 probe (above, without adapter) and a PL31K25 with a 1/8'' NPT adapter (lower) are shown in the picture.
Right: Ferrule installation direction for compression fitting



This probe can be purchased with optional wall-mount fitting (M10) for mounting on the pan. This fitting is made by stainless steel and food grade silicon. One brass ferrule is provided for compression fitting. The fitting can be used to form a liquid or pressure tight seal. With fitting, use can also adjust the probe length to be inserted into the pan.

Specifications:
